Hybrid epoxy-cured polyester resin is a composite material that combines the properties of epoxy resin and polyester resin. It is cured by a specific curing agent to form a cured product. It has high strength and toughness, chemical resistance, heat resistance and easy processing. It is used in industrial manufacturing, anti-corrosion engineering and construction fields.
| Polyester Resins For Hybrid Formulations | ||||||
| Type | Ratio | Acid Value (mgKOH/g) | Viscosity(pa-s/200℃) | Glass Transition Temp (Tg℃) | Curing Time (℃/min) | Properties |
| YZ9801 | 50/50 | 66-75 | 2.0-5.0 | ≥50 | 180℃×15′ | For physical extinction powder |
| YZ9802 | 50/50 | 66-75 | 2.0-5.0 | ≥50 | 180℃×15′ | High gloss, good mechanical properties, particularly wear-resistant coating |
| YZ9811 | 50/50 | 66-75 | 2.0-5.0 | ≥50 | 180℃×15′ | High gloss, good mechanical properties |
| YZ9855 | 50/50 | 59-69 | 1.0-4.0 | ≥52 | 180℃×15′ | Good leveling, high gloss, good mechanical properties, resistant to gas baking below 200℃, TMA-free |
| YZ9804 | 60/40 | 40-48 | 2.5-5.5 | ≥52 | 180℃×15′ | For low-gloss powder |
| YZ9816 | 60/40 | 49-57 | 3.0-6.0 | ≥52 | 180℃×15′ | High gloss, good impact |
| YZ9816T | 60/40 | 45-55 | 3. 5-6.5 | ≥53 | 180℃×15′ | Low-gloss powder coatings with excellent mechanical properties can be prepared |
| YZ9866 | 60/40 | 48-56 | 2.0-5.0 | ≥51 | 180℃×15′ | High gloss, good leveling |
| YZ9805 | 75/25 | 20-26 | 2.0-5.0 | ≥54 | 180℃×15′ | For chemical extinction powder |
| YZ9812 | 70/30 | 30-38 | 5.0-9.0 | ≥58 | 180℃×15′ | Combined with E-12 epoxy resin, it can be used to prepare a 70/30 hybrid powder for indoor applications |
| YZ9846 | 60/40 | 48-56 | 4.0-8.0 | ≥56 | 180℃×15′ | Combined with E-12 epoxy resin ,it can be used to prepare a 60/40 hybrid powder for indoor applications |
Outdoor TGIC-cured polyester resin is a special polyester resin, which is characterized by the use of TGIC (triglycidyl isocyanurate) as a curing agent. It has fast curing ability and is environmentally friendly and harmless. The cured product has high hardness, good wear resistance, and strong chemical corrosion resistance. Outdoor TGIC-cured polyester resin is suitable for outdoor building products, high-gloss products, semi-gloss products, engineering machinery, and coiled steel powder.
| Polyester Resins For TGIC-Based Formulations | ||||||
| Type | Ratio | Acid Value (mgKOH/g) | Viscosity(pa·s/200℃) | Glass Transition Temp (Tg℃) | Curing Time (℃/min) | Properties |
| YZ9803 | 93/7 | 31-37 | 3.0-6.0 | ≥60 | 200℃×12′ | General-purpose weather-resistant type, can also be cured with HAA |
| YZ9803A | 93/7 | 31-37 | 5.0-8.0 | ≥58 | 190℃×12′ | High gloss, flex-resistant, fast cure, and more resistant to baking |
| YZ9803Ap | 93/7 | 31-37 | 5.0-8.0 | ≥60 | 190℃×12′ | High gloss,flex-resistant. fast cure, and more resistant to baking |
| YZ9803Z | 93/7 | 31-37 | 5.5-8.5 | ≥62 | 190℃×12′ | High gloss,flex-resistant, good performance, relatively high Tg |
| YZ9810 | 93/7 | 30-36 | 4.0-7.0 | ≥65 | 200℃×12′ | Building-grade materials, excellent weather resistance |
| YZ9820 | 93/7 | 30-36 | 3.0-6.0 | ≥64 | 200℃×12′ | Building-grade materials, good leveling |
| YZ9820D | 93/7 | 31-37 | 2.0-5.0 | ≥63 | 200℃×12′ | Good leveling, suitable for the preparation of low-gloss or high-gloss aluminum profile powder coatings |
| YZ9820Q | 93/7 | 28-38 | 2.0-6.0 | ≥63 | 200℃×12′ | Anti-direct gas baking, good leveling, good weather resistance, excellent outdoor stability |
| YZ9820M | 93/7 | 28-38 | 2.0-6.0 | ≥64 | 200℃×12′ | Can be used for spraying friction guns, good leveling, and excellent outdoor stability |
| YZ9830 | 93/7 | 30-36 | 4.5-7.5 | ≥66 | 200℃×12’ | Boiling resistance, fast reaction speed,building-grade materials |
| YZ9830A | 93/7 | 31-37 | 4.5-7.5 | ≥65 | 200℃×12′ | Boiling resistance, excellent weather-resistant, sand grain transfer |
| YZ9835 | 93/7 | 30-36 | 2.5-5.5 | ≥61 | 200℃×12′ | excellent leveling, good mechanical properties, building-grade materials |
| YZ9839 | 93/7 | 27-33 | 3.0-6.0 | ≥62 | 200℃×12′ | Sand grain powder coatings with low gloss can be prepared for, general industry |
| YZ9843 | 93/7 | 28-34 | 2.5-5.5 | ≥62 | 200℃×12′ | Suitable for flat, extinction powder |
| YZ9853 | 93/7 | 28-34 | 4.0-7.0 | ≥61 | 200℃×12′ | Suitable for extinction powder, sand grain, and building-grade materials |
| YZ9853L | 93/7 | 28-34 | 3.0-7.0 | ≥61 | 200℃×12′ | Good leveling,building-grade materials, can prepare low-gloss powder coatings |
| YZ9853A | 93/7 | 27-33 | 3.5-6. 5 | ≥62 | 200℃×12′ | Suitable for extinction powder, sand grain, and general industry |
| YZ9863 | 93/7 | 31-37 | 3.0-6.0 | ≥62 | 200℃×12′ | Suitable for sand grain, general industry |
| YZ9870 | 93/7 | 31-37 | 4.0-7.0 | ≥65 | 200℃×12′ | Boiling resistance, building-grade materials |
| YZ9890 | 93/7 | 30-36 | 2.5-5.5 | ≥58 | 200℃×12′ | Super weather resistance, transparent powder |
| YZ9898 | 93/7 | 30-40 | 3.0-7.0 | ≥60 | 160℃×20′ | Fast cured at low T, super weather resistance, good boiling resistance, anti-frost, resistance to direct burning oven baking |
| YZ9873 | 93/7 | 28-33 | 3.0-6.0 | ≥60 | 200℃×15′ | Suitable for sand grain, general industry |
| YZ9850 | 92/8 | 40-48 | 2.0-5.0 | ≥66 | 200℃×12′ | Wood grain transfer, boiling resistance, building-grade materials |
| YZ9880 | 94/6 | 27-33 | 5.0-9.0 | ≥66 | 200℃×12′ | Building-grade materials |
| YZ9817 | 93/7 | 30-38 | 2.5-5.5 | ≥56 | 200℃×12′ | Economy-grade |
Outdoor HAA-cured polyester resin is a polyester resin product that uses HAA (β-hydroxyalkylamide) as a curing agent, mainly used for outdoor coating needs. Compared with the TGIC curing agent, the HAA curing agent has lower toxicity and irritation, and can maintain good coating performance in outdoor environments. HAA curing agent has high reactivity and can rapidly cure at lower temperatures.
| Polyester Resins For HAA-Based Formulations | ||||||
| Type | Ratio | Acid Value (mgKOH/g) | Viscosity(pa·s/200℃) | Glass Transition Temp (Tg℃) | Curing Time (℃/min) | Properties |
| YZ9813 | 96/4 | 20-26 | 3.5-6.5 | ≥57 | 180℃×12′ | Good leveling |
| YZ9813A | 95/5 | 27-33 | 3.0-6.0 | ≥57 | 180℃×12′ | Good leveling.good mechanical properties |
| YZ9819M | 95/5 | 27-33 | 3.0-6.0 | ≥56 | 180℃×12′ | Excellent weather resistance, excellent anti-yellowing, friction gun |
| YZ9848 | 95/5 | 32-40 | 5.0-8.0 | ≥64 | 165℃×12′ | Fast cured at low T, good boiling resistance, anti-frost, suitable for preparing various orange grain powders |
| YZ9860 | 95/5 | 29-35 | 2.0-6.0 | ≥65 | 190℃X10-12′ | Building-grade materials, good mechanical properties, good storage stability |
| YZ9849 | 95/5 | 28-34 | 1.5-4.5 | ≥60 | 180℃×12′ | High gloss, good leveling. Low-light power coatings can be prepared |
| YZ9859 | 95/5 | 29-35 | 2.5-5.5 | ≥60 | 200℃×12′ | Good leveling, low-gloss power coatings can be prepared |
| YZ9859A | 95/5 | 29-35 | 3.0-6.0 | ≥64 | 200℃×12′ | Suitable for flat, high gloss, and matt powder coatings |
| YZ9883 | 96/4 | 24-30 | 2.5-5.5 | ≥60 | 180℃×12′ | General industry, good leveling |
| YZ9869 | 90/10 | 70-76 | 2.0-6.0 | ≥63 | 180℃×10-12′ | Good mechanical properties, good storage stability and fast curing speed, and good boiling resistance |
| YZ9829 | 96/4 | 17-23 | 3.0-7.0 | ≥56 | 180℃×10-12′ | Good mechanical properties and slow curing speed |
| YZ9857 | 95/5 | 28-34 | 2.5-5.5 | ≥56 | 180℃-12′ | Building-grade materials, good leveling, suitable high gloss and matt powder coatings |
Two-component TGIC polyester resin is a polymer compound made from polyols and polyacids through polycondensation reaction, in which TGIC (triglycidyl isocyanurate) is used as a curing agent or crosslinking agent in conjunction with another component (usually the main body of polyester resin). It has desirable weather resistance, chemical corrosion resistance, heat resistance, and mechanical properties, and the coating formed after curing has high hardness, good gloss, and strong adhesion. It is mainly used in powder, coil, and automotive coatings, and other occasions requiring high weather resistance, high gloss, and desirable mechanical properties.
| Two-component TGIC polyester resin | ||||||
| Type | Ratio | Acid Value (mgKOH/g) | Viscosity(pa-s/200°C) | Glass Transition Temp (Tg°C) | Curing Time (°C/min) | Properties |
| YZ9818 | 95/5 | 19-25 | 4.5-7.5 | ≥63 | 200℃×12′ | Combined with YZ9878, a two-component low-gloss powder can be prepared |
| YZ9828 | 95/5 | 17-23 | 5.5-8.5 | ≥63 | 200℃×12′ | Combined with YZ9868 or YZ9878,two-component transfer and low-gloss powders can be prepared |
| YZ9868 | 90/10 | 48-56 | 2.5-5.5 | ≥64 | 200℃×12′ | Combined with 9828, two-component transfer and low-gloss powders can be prepared |
| YZ9878 | 90/10 | 48-56 | 5.5-8.5 | ≥66 | 200℃×12′ | Resistant to boiling water, wood grain transfer, and can prepare two-component low-gloss powder |
| YZ9895 | 95/5 | 18-24 | 3.0-6.0 | ≥60 | 200℃×12′ | Combined with YZ9899, a two-component super weatherability powder can be prepared |
| YZ9899 | 90/10 | 49-55 | 2.0-4.0 | ≥64 | 200℃×12′ | Resistant to water boiling, combined with YZ9895, can preparea two-component super weatherability powder |
| YZ9838 | 90/10 | 48-56 | 4.0-7.0 | ≥67 | 200℃×12′ | Good weather resistance, good mechanical properties, resistance to water boiling ,can prepare two-component transfer, and low-gloss powders |
| YZ9808Z | 95/5 | 18-25 | 7.0-10.0 | ≥60 | 200℃×12′ | Construction-grade low-acid resin can be used to prepare a two-component anti-flex powder. Combined with YZ9838Z, it can produce low-gloss powder with a gloss level of around 25 |
| YZ9838Z | 90/10 | 50-58 | 3.5-6.5 | ≥62 | 200℃×12′ | Construction-grade high-acid resin can be used to prepare a two-component anti-flex powder. Combined with YZ9808Z, it can produce low-gloss powder with a gloss level of around 25 |
| Isocyanate cured polyester resin | ||||||
| Type | Ratio | Hgdroxyl Value (mgKOH/g) | Viscosity(pa-s/200℃) | Glass Transition Temp (Tg℃) | Curing Time(℃/min) | Properties |
| YZ9858 | / | 27-33 | 4.0-7.0 | 62-65 | 200℃×15′ | Cured in 87/13 ratio with B1530.good mechanical properties. economical type |
| YZ9888 | / | 35-50 | 4.0-7.0 | 61-64 | 200℃×15′ | Cured in an 80/20 ratio with B1530, good leveling, and good mechanical properties |
| YZ9889 | / | 90-120 | 4.0-8.0 | ≥55 | 200℃×15′ | Cured in a 65/35 ratio with B1530, resistant to boiling water and transfer printing |













Practical Measures to Improve Coating Leveling (Flowability) 1. Formulation Optimization: Appropriate Resin Ratio Adjusting the mass ratio of polyeste...
View MoreKey Factors Affecting Shelf Life: 1. Temperature Control: Temperatures below 30°C significantly extend shelf life; temperatures above this accelerate ...
View MoreWhat Core Application Scenarios Rely on Two-Component TGIC Polyester Resin? Two-component TGIC (triglycidyl isocyanurate) polyester resin is widely ad...
View MoreGlobal Green Transition: How Do Environmental Policies Drive Powder Coating Adoption? As countries strengthen environmental regulations in 2025, the i...
View MoreHow Does Jiangsu BESD Ensure the Quality and Performance of Its Polyester Resins for Powder Coatings?
Since its establishment in 1998, Jiangsu BESD New Materials Co., Ltd has been committed to the production of polyester resins for powder coatings. Through continuous innovation and technological upgrading, it has become a enterprise in this field. To maintain a position in the highly competitive market, the quality and performance of products are crucial factors. BESD ensures that the quality and performance of its polyester resin products meet the high standards of the industry through a series of strict measures and management systems.
Technological innovation, laying the foundation for quality
One of BESD's important measures to ensure the quality of polyester resins is technological innovation. The company has an experienced and creative R&D team that continuously optimizes product formulas and improves production processes. By introducing the world's advanced equipment and technology, BESD is able to ensure the performance of its polyester resin products in terms of durability, adhesion, chemical resistance and mechanical properties.
In addition, the company is also committed to meeting the specific needs of customers and providing customized polyester resin solutions. For example, different industries have different performance requirements for powder coatings. The construction industry pays more attention to weather resistance, the home appliance industry emphasizes appearance gloss and wear resistance, and the automotive industry has high requirements for corrosion resistance. Through a deep understanding of customer needs, BESD is able to produce polyester resin products suitable for various application scenarios, ensuring that its products can adapt to different market needs and meet customers' special requirements.
Strict quality management system
Another key factor in ensuring product quality is a strict quality management system. BESD has passed the ISO:9001 quality management system certification, which means that the company manages every link of product design, production, inspection and delivery in accordance with international standards. Through standardized processes, the company can ensure the quality consistency of each batch of polyester resin products, thereby avoiding the problem of quality differences between batches.
In the specific quality management process, BESD starts with the procurement of raw materials and checks every level to ensure that all raw materials meet high quality standards. During the production process, the company uses advanced automated production lines to reduce errors caused by manual intervention and further improve the stability and consistency of the products. Before leaving the factory, each batch of products will undergo strict physical and chemical performance testing to ensure that it meets customer requirements and industry standards.
Advanced production technology and equipment
Advanced production technology and equipment are another important factor for BESD to ensure product quality and performance. The company has modern automated production lines in Yangzhou Chemical Industry Park, which not only improve production efficiency, but also enable precise control of the production process. Automated equipment can ensure that each production step is carried out according to predetermined parameters, thus avoiding quality fluctuations that may be caused by manual operation.
Environmental management and sustainable development
In addition to quality management, BESD also pays attention to the environmental management system and has passed the ISO:14001 environmental management system certification. The company strictly controls the emission of pollutants that may be generated during the production process and adopts environmentally friendly processes to ensure that the impact of the production process on the environment is minimized. As a manufacturer of polyester resins for powder coatings, BESD's products themselves do not contain solvents, have extremely low VOC emissions, and meet environmental protection requirements.
Perfect after-sales service system
In addition to maintaining high standards in product production and quality management, BESD's after-sales service system is also an important part of ensuring product quality and performance. The company pays attention to communication with customers, understands the problems encountered by customers during product use, and provides timely and effective technical support. Through close contact with customers, BESD is able to obtain market feedback in a timely manner, thereby improving and optimizing products according to actual needs.
